United Kingdom - Defence High Frequency Communications Service (DHFCS) Radio Frequencies

Defence High Frequency Communications Service (DHFCS)
United Kingdom Communication systems - Joint




Description

The Defence High Frequency Communications Service (DHFCS) provides long distance strategic communication between Army units, RAF aircraft, Royal Navy warships and UK headquarters using HF communications.

It has subsumed the following legacy systems:



Base of operations

The system is based on six sites in the UK and four overseas.
In the UK they are Crimond, Inskip, Kinloss, Forest Moor, Penhale Sands and St Eval.
Overseas sites are Cyprus, Gibraltar, Ascension Island and the Falklands Islands.

The Network Control Station (NCS) is at Forest Moor (TASCOMM); it controls all DHFCS assets worldwide. The alternative network control centre (ANCS) is at Kinloss.

The system includes Automatic Link Establishment (ALE), Automatic Repeat Request (ARQ) and Automatic Link Management (ALM) and provides both voice and data services.

DHFCS was declared in service in March 2008 with the delivery of the ANCS at Kinloss.

Network Frequencies

There are H24 (flightwatch) operations centres at DHFCS Forest Moore and DHFCS Kinloss

   Callsign   Location   Watch Frequencies Notes
  ARCHITECT   UK
(FOREST MOOR / KINLOSS)
(TASCOMM)


4742
5702
9031
11247
13257
18018
ALE CALLSIGN IS XSS
 HAVEN ASCENSION
4742
9031
11247

CYPRUS CYPRUS
4742
9031
11247
 4742 - (H+15 weather broadcast when active)
VIPER  MT PLEASANT - FALKLAND ISLANDS

4742

11247

NOTE: H+35 weather broadcasts when active.

1. Flight Watch available for notified flights.

2. Aircraft not fitted with ALE are to scroll through the frequencies in order to select the best reception. Transmissions are to be made at 15 sec intervals before changing to the next guard frequency.

VOLMET   5450

 11253
H24

00/30
BENSON, COLTISHALL, CONINGSBY, LEEMING, LEUCHARS, LOSSIEMOUTH, MARHAM, ODIHAM, SHAWBURY, HANNOVER, GEILENKIRCHEN, GARDERMOEN, TRONDHEIM

06/36
ALDERGROVE, BIRMINGHAM, BRIZE, NORTON, CRANWELL, EAST MIDLANDS, KINLOSS, LYNEHAM, MANCHESTER, NORTHOLT, PRESTWICK, STANSTED, WADDINGTON

12/42
SPLIT, BUDAPEST, BARI, GIOIA DEL COLLE, AVIANO, RIMINI, ANCONA, ROME, CONSTANTA, BUCHAREST, PRISTINA, SKOPJE

18/48
KEFLAVIK, ASCENSION, BANJUL, DAKAR,GIBRALTAR, MOMBASA, NAIROBI, RIO DE JANEIRO, MONTEVIDEO, BRIZE, NORTON,LYNEHAM, WADDINGTON, FUJAIRAH

24/54
ADANA, AKROTIRI, AL UDEID, AMMAN,BASRAH, BAHRAIN, CARIO, KEBUL,KUWAIT, MUSCAT, AL KHARJ, SALALAH,THUMRAIT





Information source: US DoD FLIP




THE FOLLOWING ARE REFERENCED MATERIAL FROM A NOW DEFUNCT HF NETWORK AND ARE NOT BE CURRENT
THESE FREQUENCIES ARE INCLUDED FOR REFERENTIAL PURPOSES ONLY

The previous HF network (pre-2006) was the STCICS.  The following information applies to the STCICS and is shown as an archival reference only, although some frequencies do apply as discreets for DHFCS (although unconfirmed via our sources).

STCICS HF FREQUENCIES

CH Freq CH Freq CH Freq CH Freq
A 11.205 DW 9.031 KD 3.867 SA 2.762
AB 5.693 E 3.149 KH 12.057 SE 14.812
AC 8.156 EF 5.720 KJ 4.718 ST 2.591
AD 9.010 EH 11.259 KP 2.641 TG 6.724
AE 3.939 EI 23.270 KR 4.484 TO 3.391
AF 9.022 EK 11.184 KT 5.420 TQ 3.345
AG 4.745 EM 15.025 KW 2.261 TS 5.684
AH 3.390 EN 15.076 KX 2.577 TW 4.709
AK 3.038 EP 15.040 L 5.447 UA 4.724
AP 11.181 EX 11.235 LA 3.036 UB 10.919
AQ 2.396 EZ 11.253 LB 3.092 UR 17.979
AW 4.042 F 13.257 LC 6.701 UT 4.540
AZ 23.281 FA 3.101 LD 15.046 VE 11.217
B 6.739 FG 11.208 LE 15.072 W 5.747
BA 17.970 FS 4.742 MB 2.266 WG 3.125
BE 18.018 FT 13.218 MC 5.270 WM 3.026
BF 3.083 FV 15.064 MD 18.850 X 3.224
BJ 17.988 FW 3.131 ME 14.460 XA 5.403
BK 3.945 G 3.915 MS 3.218 YC 11.241
BL 11.268 GA 15.061 NJ 5.705 YM 13.211
BS 18.000 GD 2.274 PA 3.302 YP 23.250
BT 2.350 GT 26.385 PE 6.760 YZ 20.030
BX 8.989 H 15.031 PF 10.634 ZF 3.763
CA 6.736 HE 3.942 PH 8.971 ZZ 5.714
CM 18.009 HJ 8.983 PK 5.095 xx 2.031
CO 23.245 HK 9.034 PO 6.715 xx 2.404
CY 3.119 HM 6.748 PR 3.864 xx 3.943
CZ 29.800 HO 13.206 PZ 14.724 xx 5.392
D 4.706 HW 11.247 QB 3.512 xx 7.919
DA 5.436 HX 23.257 QR 8.972 xx 10.375
DB 15.091 HZ 13.248 QV 3.095 xx 10.830
DH 15.013 I 13.236 RA 8.190 xx 12.198
DM 8.998 IN 17.982 RD 6.691 xx 14.568
DQ 17.995 IP 27.000 RE 5.178 xx 16.344
DS 4.739 J 8.980 RM 3.110 xx 4.785
DT 18.024 KA 3.380 RZ 9.459 xx 10.585
   Callsign   Location   Watch Frequencies
   Architect   UK (GROUP A) 4742, 5714, 6739, 9031, 11205, 18018
(GROUP B) 4540, 8190, 13257, 15031
(24Hr) 2591, 11247
Group A has QNH at H+00 and airfield colour-state at H+30.
Group B has RAF Germany airfield flying states at H+15 and H+45.
   Cyprus Flt Watch   Cyprus 4730, 9031 (1600-0500z), 11247, 18018 (0500-1600z)
4730 and 18018 have weather at H+15.
   Gibraltar Flt Watch   Gibraltar 4742 (2000-0700z), 11247 (0700-2000z)
   Haven   Ascension 4742 (2000-0800z), 9031(0800-2000z), 11247
All freqs have weather at H+45.
   Viper   Mount Pleasant, Falkland Is. Any of the above.

GROUND CONTROLLED INTERCEPTION

On HF the following air defence radar stations can be heard.

Buchan, Boulmer ,Neatishead, Benbecula

Frequencies in use are from the same pool as the STCICS above. On any day you can hear stations ask Architect for designator frequencies to work with the three above, mostly Neatishead.

GUIDE TO MONITORING STCICS
-To find which frequencies are active listen to the Architect weather broadcast at H+00 and H+30 (see above).
-If the UKADGE circuits are active there will be an announcement following weather with code letters for active freqs.
EG '...additional information 2..PK..tack..401C..tack..AG (repeated twice).

-The first number indicates which air defense radar is active.
1- Buchan, Boulmer, Benbecula
2- Buchan
3- Boulmer
4- Neatishead

-The first 2-letter group is the code for the active HF frequency from the list (above), sometimes refered to as the Jorsk Frequency. This is the main operating frequency.

-The third group is the Charlie Squared channel, where AWACS aircraft pass their radar data.

Channel  Frequency
401A 2250.5
401B 33?
401C 4478.5
401D 6673.5
401E 8500.5

 -The final group is 'chick co-ordination' where HF capable combat aircraft can be passed target information, etc.

-Therefore the EG given would be Buchan as ADR, using 5095 KHz for voice traffic, AWACS on 4478.5 KHz and 'chicks' are on 4745 KHz.

RAF/NATO 'K Series'
A new set of codes seem to be being used by RAF and other NATO forces. The 'K series' (real name unknown).

Channel Frequency Channel Frequency
Golf 02 3235 Kilo 26 UHF?
Golf 08 4572 Kilo 27 UHF?
Hotel 05 9010 Kilo 28 Beaver HF?
Kilo 01 HF? Kilo 30 4477
Kilo 04 HF? Kilo 31 5045
Kilo 05 4520 Kilo 33 5385
Kilo 06 4020 Kilo 34 5463.5
Kilo 09 4920 Kilo 36 4012
Kilo 10 5173 Kilo 55 UHF?
Kilo 11 5277.5 Kilo 56 UHF?
Kilo 12 5290 KJ 02 3357
Kilo 14 UHF? KJ 04 3805
Kilo 15 7860 KJ 07 5280
Kilo 17 3304.5 KJ 11 ?
Kilo 18 4860.5 KJ 28 UHF?
Kilo 19 UHF? KJ 29 UHF?
Kilo 22 4785 KJ 37 5910 (poss.)
Kilo 24 4779 TL 04  6237 (poss.)
Kilo 25 HF?

ROYAL NAVY

Royal Naval aircraft and ships often communicate about helicopters flying from land to ship or vice versa.

  Freq   Base
5.696     Culdrose Ops (Day)
3.921     Culdrose Ops (Night)
8.993     Portland ops
8.977     Yeovilton Ops (Primary)
6.685     Yeovilton Ops (Secondary)
6.706     Rescue Ops Center (Day)
3.093     Rescue Ops Center (Night)
6.730     FRADU "Grove Control" (P)
3.080     FRADU "Grove Control" (S)
9.013     Prestwick (Primary)
6.700     Prestwick (Secondary)
6.688     Yeovilton Ops

Updated 9 November, 2012.
